Operation
5-36 October 2019 16K PLUS
Automatic Mode - Continued
Operating the Machine in Automatic Mode - Continued
3. Auto Load Sequence for Sticky Bales, or Traveling Down-Hill.
This sequence can be used when the power slide needs assistance pushing the bales back.
1. The operator picks up a pair of bales and the monitor positions the power slide in front of them.
(Steps 1 through 6 of the Auto Load Sequence)
2. Use the Bed Up button to raise the bed.
• Adjust the incline of the bed to assist the power slide.
• If necessary, the Dump Reset can be used to lower the bed.
3. When ready, press the Load Reset switch to open the alignment arms.
• When the alignment arms are fully open, the monitor activates the power slide to push the bales back.
• If the bales do not move, the power slide will continue to push against them. It is still possible to raise the
bed even more with the Bed Up switch if desired.
Note: To stop power slide exit the Auto Load screen by pressing the Manual Load or Manual Stack buttons.
4. After the bales are pushed back, the monitor returns the power slider to its home position under loader.
• The bed lowers automatically.
• The loader lowers for time specied in the Conguration screen.
4. Full Load Sequence
When picking the last row of bales, the monitor will recognize a full load.
1. After pushing the last row of bales back, the power slide signals the operator by not returning to the home position.
2. Push the Auto Load button to close alignment arms.
• When the squeeze pressure has been reached, the slider will return to the home position.
3. Pressing the Hitch Inline button briey will move the hitch inline automatically.
Note: When a full load has been detected the loader will not lower in Auto Mode until the load has been
stacked.
