Morris PROAG 16K PLUS - Stacking Bales

Operation
16K PLUS October 2019 5-37
Automatic Mode - Continued
Operating the Machine in Automatic Mode - Continued
5. Stacking Bales
Stacking sequence begins with a full load, the bed down and the alignment arms closed, and the 16k PLUS aligned
with the stack.
Warning: Stand Clear of stack. As a precaution, check surrounding area to be sure it
is safe to raise bed.
1. Press the Bed Up button until the bed is 70-80 degree angle.
• If the pushoff is not in, the monitor retracts it rst.
• The bed goes up as long as the button is pressed. Releasing the button stops the bed.
2. Back up 16k PLUS until the corner of the bottom bale on the Bale Runner comes into contact with the back
stop.
3. When the bed is raised above the midway position, the loader can be lowered with the Load Reset button which
will rst open the alignment arms.
• WARNING: Ensure the bed is sufciently raised to prevent top row of bales from dropping when lowering
the loader.
Tip: Lowering the loader allows stacks to be placed tightly side-by-side. See “Tips and Techniques” for
more information.
4. Press the Bed Up button until bed is completely raised.
• Some times it is helpful to reverse the tractor while performing this step to ensure a tight stack.
• The screen indicates a change in button functions by replacing the “Hitch Inline” and “Hitch Offset” text with
“Pushoff Retract” and “Pushoff Extend”.
5. Press the Pushoff Extend button while driving slowly forward to assist in unloading the bales.
• The pushoff will extend as long as the Pushoff Extend button is pressed.
6. Press the Dump Reset button once 16k PLUS is clear of the stack.
• The pushoff will retract.
• When the pushoff is fully retracted the bed starts down.
• The operator may release the Dump Reset button after the bed has lowered for 1.5 seconds.
• The bed continues to lower automatically. Pressing the Bed Up button will stop the automatic lowering.
• The loader raises automatically when the bed has been lowered below the midway position.
• After the loader has been raised, the bed continues to lower until it is all the way down.
• The alignment arms close. Pressing the Load Reset button will stop the arms from closing.
• The hitch moves inline. Pressing the Hitch Offset button will stop the hitch from moving in line.
Danger
Always stay clear of stacker bed being raised,
lowered or in elevated position. Ensure
cylinders are completely lled with hydraulic
uid - bed may fall rapidly causing injury or
death.
Warning
Stand Clear of stack.
As a precaution, check surrounding area to
be sure it is safe to raise bed.
