Morris PROAG 16K PLUS - Loader up; Loader down

Troubleshooting
Problem
Correction
Cause
8-18 October 2019 16K PLUS
Loader Up
Loader Down
Crash Avoidance
Check current output
Check valve solenoid
Crash Avoidance
Check Operating Mode
Manual Mode - No restrictions
Auto Mode - If the bed is down, use “Measure -
Sensors” menu to ensure the hitch offset sensor
is true.
Auto Mode - If the bed is up, use the “Measure -
Sensors” menu to ensure the bed mid sensor is
true.
NOTE: If the bed has been lowered below the
mid-position with the loader down, the
operator MUST switch into one of the
Manual screens to raise the loader.
Use “Measure - Outputs” menu to check amperage
going to the Loader valve. The monitor should
display a positive amperage when raising the
loader. (If there is a broken wire or shorted wire
to the valve, the monitor may show an error
message.)
Use procedure described in “Checking Valve
Solenoids” to check the operation of the valve.
Both Manual and Auto Mode: If the bed is down,
use the “Measure - Sensors” menu to ensure the
hitch offset sensor is true and the bed down switch
is true.
If the bed is raised, use “Measure - Sensors” menu
to ensure the bed mid sensor is true.
Note: The loader will not lower if neither the
bed mid or the bed down sensors are
true.
Auto Mode only: The loader cannot be lowered
in Auto Mode if the slider is not ready. Look for
the Green Check Mark in the top right corner
of the Auto screen. If the Green Check Mark is
not displayed, see “Resetting Power Slide” for
instructions on how to set the Power slide in the
home position.
Continued on next page . . .
