Troubleshooting
Problem Cause
Correction
16K PLUS October 2019 8-19
Check Operating Mode
Check Current Output
Check valve solenoid
Crash Avoidance
Check operating mode
Auto Mode only: The loader cannot be lowered in
Auto Mode if the Bale On sensor is true. (This is
done to prevent dropping bales accidentally.) Look
for the bale icon in the lower left corner of the Auto
screen, or use the “Measure - Sensors” menu to
check the state of the Bale On sensor.
Auto Mode only: The loader cannot be lowered in
Auto Mode if the computer thinks it has a full load.
(This is done to prevent dropping the last row of
bales accidentally.) If the power slide stalls during
the rst 30 inches of travel when pushing the bales
back in the Auto Load sequence, the computer
assumes the stacker has a full load. To reset the
computer, the bed must be raised to the “bed Up”
position, or alternatively, use a piece of ferrous
metal to turn on the “Bed Up” sensor momentarily.
Use “Measure - Outputs” menu to check amperage
going to the Loader valve. The monitor should
display a negative amperage when lowering
the loader. (If there is a broken wire or shorted
wire to the valve, the monitor may show an error
message.)
Use procedure described in “Checking Valve
Solenoids” to check the operation of the valve.
None
Manual mode: Use the soft keys in “Manual Stack”
screen to ensure check if the grab hooks work. If
the grab hooks do not work in manual mode, check
the valve solenoid.
Auto Mode: If the grab hooks do not engage in
Auto Mode, it is likely the Bale On sensor is not
being activated by the bale. The appearance of the
grey bale in the bottom left corner of the screen
Auto screen indicates the bale-on sensor has been
activated.
Auto Mode: If the grab hooks do not disengage
in Auto Mode, it is likely the Bale On sensor is not
turning off. Check there is nothing jammed in the
sensor pad to hold the pad down. Then check the
ferrous sensor is working properly.
Continued on next page . . .
Loader Down - Continued
Grab Hooks Engage/
Release
