Menu Screens - Continued
Adjust Menu - Continued
Power Slide Return
• The parameter group “Power Slide Return” is locked. The parameters within this group is set at the factory
and should not be changed. Adjusting parameters within this group could have severely negative affect on the
performance of the machine.
Tech Adjustments
• The parameter group “Tech Adjustments” is locked. The parameters within this group is set at the factory and should
not be changed. Adjusting parameters within this group could have severely negative affect on the performance
of the machine.
Measure Menu
The Measure menu contains important information about the monitor/controller and the 16k PLUS machine. This
information can be useful for monitoring the 16k PLUS machine’s performance or diagnosing errors.
Note: No adjustments can be made from the Measure menu.
• From the Main menu, press F2 to enter the Measure Menu.
• Use the UP/DOWN keys to select the measure group. Refer to Table 1 for a list of measure groups and the
information found within.
• Press OK to enter the selected group.
• If there is more information lower or higher than that displayed on the page, use the UP/ DOWN keys to scroll to
it.
• Press the key to return to the Adjust menu.
-OR-
• Press the key
Sensors
1. Alignment Arms: When the alignment arms are completely open, the sensor will read true.
2. Bale On: When the bale on pad is depressed, the sensor will read true.
3. Bed Down: When the bed is securely resting in the cradle, the sensor will read true.
4. Bed Mid: When the bed is raised above 45 degrees, the sensor will read true.
5. Bed Up: When the bed is raised to the vertical position, the sensor will read true.
6. Hitch Inline: When the hitch is completely in line, the sensor will read true.
7. Hitch Offset: When the hitch is completely offset, the sensor will read true
8. Loader Up: When the loader is completely raised up. the sensor will read true.
9. Push Off In: When the push off is completely retracted, the sensor will read true.
10.Squeeze Pressure: This sensor reads the pressure (in psi) in the alignment arm cylinders.
11.Power Slide Counter: This sensor keeps track of the location of the power slide as it moves along the bed. The
“0” location should be approximately at the foot of the loader. The home position should be below -5.
