Operation
16K PLUS October 2019 5-49
Menu Screens - Continued
Measure Menu - Continued
Outputs
This menu shows the operator the electrical current
the Control Box is sending to open and close the valve.
• Hydraulic functions that can be sped up or slowed
down with the Control Box (the loader, power slide,
hitch and alignment arms) have the units of milliamps.
A positive number indicates that the valve is being
opened in one direction, and negative indicates the
opposite directions direction. (as indicated below)
• All other hydraulic functions operate either true or
false. When the function reads true, the Control
Box is sending 12 volts to the valve to activate
the corresponding function. (The speed of these
functions can not be controlled by the computer.)
Note: There are limit screws on the valve that can
be used to limit the speed of any function.
• Loader: A positive reading opens the valve to raise
the loader. A negative reading opens the valve to
lower the loader.(milliamps)
• Power Slide: A positive reading opens the valve
to move the power slide back. A negative reading
opens the valve to return the power slide to the
front.(milliamps)
• Hitch: A positive reading opens the valve to move
the hitch offset. A negative reading opens the valve
to pull the hitch inline.(milliamps)
• Alignment Arms: A positive reading opens the
valve to close the alignment arms. A negative
reading opens the valve to open the alignment
arms.(milliamps)
• Push Off In: Reads true when power is supplied
to valve to pull the push off in.
• Push Off Out: Reads true when power is supplied
to valve to push the push off out.
• Grab Hooks In: Reads true when power is
supplied to valve to engage the grab hooks.
• Grab Hooks Out: Reads true when power is
supplied to valve to disengage the grab hooks.
• Bed Up: Reads true when power is supplied to
valve to raise the bed.
• Bed Down: Reads true when power is supplied to
valve to lower the bed.
Limit Screw
Set Screw
