16K PLUS October 2019 9-9
Sensors Mounting
Item Part No. Description Qty
1 11584 Rubber Computer Mount - 1/2” ........................................................................................ 2
2 11585 Rubber Computer Mount - 3/4” ......................................................................................... 2
3 10295 Manual Box ....................................................................................................................... 1
4 K51552 Screw - 1/4 x 1 1/4 Lg ...................................................................................................... 2
5 11505 Sensor Assembly .............................................................................................................. 4
6 11570 Hex Nut #12 - Brass .......................................................................................................... 8
7 11571 Machine Screw #12 - 24 x 1 Lg - Brass ............................................................................ 8
8 11572 Lockwasher #12 - 0.216 ID - Brass .................................................................................. 8
9 11573 Flat Washer #12 - 0.25 ID x 0.562 OD - Brass .................................................................. 16
10 11575 Nylon Spacer - 1/4 ID x 1/2 OD x 1/4Lg ........................................................................... 8
11 K45406 XA2 Harness ..................................................................................................................... 1
12 K45802 Computer Mount ............................................................................................................... 1
13 K47316 Machine Screw #6 - 1/2 .................................................................................................... 8
14 K47317 Locknut #6 - Nylon Insert .................................................................................................. 8
15 K47328 IQAN Controler.................................................................................................................. 1
16 N22778 Locknut - 1/4 Nylon Insert ................................................................................................. 10
17 S-1193 Machine Screw - 1/4 x 3/4................................................................................................. 2
18 S-1198 Washer - 5/16 ID x 3/4 OD ................................................................................................ 8
See "Electrical Control Assembly" for Harness
