Morris PROAG 16K PLUS - Page 155

16K PLUS October 2019 9-19
Loader Assembly - Serial # K161405191 and prior
Item Part No. Description Qty
1 10439 Hydraulic Cylinder - 4 1/2 x 8 Stroke ................................................................................. 1
2 10440 Hydraulic Cylinder - 4 x 8 Stroke ....................................................................................... 1
3 11512 Idler Sprocket - 80 chain ................................................................................................... 4
K53404 Idler Sprocket - 11 tooth - 100 chain .............................................................................. 4
4 11574 Bale On Spring .................................................................................................................. 2
5 11678 Frame Bumper .................................................................................................................. 4
6 10065 Hex Bolt - 5/8 x 5-1/2 ........................................................................................................ 8
7 10104 Plate - Alignment Slider ..................................................................................................... 4
8 10180 90 Deg Elbow - JIC To ORB ............................................................................................. 9
9 10256 Loader Pin - 1 7/16 Dia ................................................................................................... 2
10 S32944 Locknut - 7/16 Unitorque (10302) ...................................................................................... 2
11 10351 Slider - 1 Thick .................................................................................................................. 4
12 10355 Grab Hook Thrust Bearing - 1/2 Dia .................................................................................. 4
13 10604 Hex Bolt - 1/2 x 2 Lg.......................................................................................................... 4
14 10827 Shackle Pin - 3/4 ............................................................................................................... 2
15 10847 Hex Bolt - 7/16 x 3 Lg Gr8 ................................................................................................. 2
16 10936 Bushing - Loader Pivot ...................................................................................................... 8
17 11309 Loader ............................................................................................................................... 1
18 11497 Loader Idler Spacer - 0.824 ID x 1 OD x 7/16 Lg - 80 chain ............................................. 8
19 11505 Sensor Assembly .............................................................................................................. 1
20 11527 Bale On Weldment ............................................................................................................ 1
21 11541 Upper Chain Plastic - White Polyethylene ......................................................................... 2
22 11570 Hex Nut - #12 - Brass ........................................................................................................ 2
23 11571 Machine Screw - #12-24 x 1 Lg - Brass ............................................................................ 2
24 11572 Lockwasher - #12 - 0.216 ID - Brass ................................................................................. 2
25 11573 Flat Washer - #12 - 0.25 ID x 0.562 Brass ........................................................................ 4
26 11575 Spacer - 1/4 ID x 1/2 OD x 1/4 Lg Nylon ........................................................................... 2
27 11576 Hex Bolt - 3/4 x 3 1/2 Lg - Gr. 8 ......................................................................................... 4
28 12166 Hydraulic Cylinder - 2 1/2 x 16 Stroke ............................................................................... 1
29 10178 Male Connector - 3/4 - 16 MORB x 3/4 - 16 MJIC ............................................................ 1
30 C26701 Locknut - 1/2 Nylon Insert .............................................................................................. 2
31 C17295 Locknut - 5/8 Nylon Insert ................................................................................................. 8
32 F-3405 Locknut - 1/2 Unitorque .................................................................................................. 14
33 K42394 Grab Hook Pivot - Lower ................................................................................................... 2
34 K42396 Grab Hook Bushing - 3 1/2 Dia ......................................................................................... 4
35 K44042 Hydraulic Cylinder - 3 1/2 x 19 9/16 Stroke ....................................................................... 1
36 K44046 Cylinder, Loader - 3 1/2 x 19 9/16 Stroke - Left ................................................................. 1
37 K47014 Grab Hook Pivot - Upper ................................................................................................... 2
38 N22778 Locknut - 1/4 Nylon Insert ................................................................................................. 4
39 S-1198 Washer - 5/16 ID x 3/4 OD x 1/16 Thick ............................................................................ 8
40 W-518 Hex Nut - 3/4 ..................................................................................................................... 4
41 W-527 Lockwasher - 3/4 ............................................................................................................... 4
42 W-539 Flatwasher - 1/2 ................................................................................................................ 10
43 W-1552 Hex Bolt - 1/4 x 1 Lg.......................................................................................................... 4
44 K45433 Grab Hook ......................................................................................................................... 1
45 K45434 Grab Hook ......................................................................................................................... 1
46 K45445 Grab Hook Pin................................................................................................................... 2
47 W-485 Hex Bolt - 1/2 x 1 1/4 Lg.................................................................................................... 2
48 C-231 Hex Bolt - 1 x 5 1/2 Lg....................................................................................................... 2
49 D-5274 Locknut - 1 Unitorque ........................................................................................................ 2
50 D-5498 Flat Washer - 1 1/16 ID x 2 OD x 1/8 Thick ....................................................................... 2
51 K51598 Bushing - Inner - 0.765 ID x 1 3/8 OD x 0.655 Lg - 100 chain ...................................... 4
52 K51599 Bushing - Outer - 0.765 ID x 1 3/8 OD x 0.822 Lg - 100 chain ...................................... 4
