16K PLUS October 2019 9-23
Loader Arm Assembly
Item Part No. Description Qty
1 10075 Hex Cap Screw - 3/8 x 1-1/2 Lg ......................................................................................... 6
2 M-3388 Locknut - 3/8 Nylon Insert (10229) .................................................................................... 6
3 10256 Loader Pin - 1 7/16 Dia ..................................................................................................... 4
4 10257 Pin - 1-7/16 Dia .................................................................................................................. 2
5 S32944 Locknut - 7/16 Unitorque (10302) ...................................................................................... 6
6 10847 Hex Bolt - 7/16 x 3 Lg Gr8 ................................................................................................. 6
7 11324 Alignment Arm Stub - Left ................................................................................................. 1
8 K55352 Pin - Alingment Arm - 1-15/16 x 8-7/32 UL - greaseable ................................................... 2
9 11331 Pin Collar .......................................................................................................................... 2
10 11332 Alignment Arm Stub - Right ............................................................................................... 1
11 K56049 Bed Extension - 2015 ..................................................................................................... 4
12 K47303 Left Arm Add On ................................................................................................................ 1
13 K47304 Right Arm Add On ............................................................................................................. 1
14 11505 Ferro Sensor Assembly ..................................................................................................... 1
15 11533 Loader Slider Plastic - Right ............................................................................................. 1
16 11534 Loader Slider Plastic - Left ................................................................................................ 1
17 11543 Bed Extension Pin - 5/8 Dia x 6 59/64 Lg ......................................................................... 4
18 11570 Hex Nut - #12 - Brass ........................................................................................................ 2
19 11571 Machine Screw #12 x 1 Lg - Brass .................................................................................... 2
20 11572 Lockwasher - #12 - Brass .................................................................................................. 2
21 11573 Flat Washer - #12 - 1/4 ID x 9/16 OD - Brass .................................................................... 4
22 11575 Spacer - 1/4 ID x 1/2 OD x 1/4Lg Nylon ............................................................................ 2
23 12461 Sensor Bracket .................................................................................................................. 1
24 W-538 Washer - 7/16 ID x 1 OD x 14 Ga ...................................................................................... 12
25 F-3405 Locknut - 1/2 Unitorque ..................................................................................................... 2
26 S32590 Hex Bolt - 3/4 x 7 Gr8........................................................................................................ 4
27 W-131 Hairpin - 5/32 .................................................................................................................... 4
28 W-493 Hex Bolt - 1/2 x 3 1/2 Lg.................................................................................................... 2
29 W-518 Hex Nut - 3/4 ..................................................................................................................... 4
30 W-527 Lockwasher - 3/4 ............................................................................................................... 4
31 10248 Slip Coat - Gallon .............................................................................................................. 0.4
32 S-752 Grease Zerk ...................................................................................................................... 2
