16K PLUS October 2019 9-27
Drive Chain Assembly
Item Part No. Description Qty
1 12167 Hydraulic Cylinder - 2 x 8 Stroke ....................................................................................... 1
2 12238 Roller Chain - #80 57P ..................................................................................................... 1
3 12240 Roller Chain - #80H 383P ................................................................................................ 2
K53406 Roller Chain - #100H 309P .............................................................................................. 2
4 11751 Power Slide - 80 chain ...................................................................................................... 1
K47300 Power Slide - 100 chain - Serial # K161405191 and prior ................................................. 1
K55367 Power Slide - 100 chain - 22 inch chain center - Serial # K161405301 to present ..... 1
5 12008 Sensor Target .................................................................................................................... 1
6 34986 Chain Link - 80 chain (K41624 - Kit includes 2 of 34986 and hardware) ......................... 4
K51099 Chain Link - 100 chain .................................................................................................... 4
7 44006 Chain Link Bolt - 5/16 x 1 5/8 shoulder x 1 7/8 Lg - 80 chain ............................................ 4
K53407 Hex Bolt - 3/8 x 3 Lg - 100 chain .................................................................................... 4
8 C33957 Carriage Bolt - 3/4 x 3 Lg .................................................................................................. 2
9 D-5272 Locknut - 5/16 Unitorque - 80 chain .................................................................................. 12
M-3388 Locknut - 3/8 Unitorque - 100 chain ............................................................................... 12
10 K45448 Hitch Bolt ........................................................................................................................... 1
11 K45683 Fork Retainer Block ........................................................................................................... 2
12 K47015 Slider Spacer - 80 chain .................................................................................................... 2
13 K47017 Hex Bolt - 5/16 x 1 1/4 Lg - 80 chain ................................................................................. 8
W-478 Hex Bolt - 3/8 x 2 Lg - 100 chain .................................................................................... 8
14 K48395 4" Red Led Lamp .............................................................................................................. 4
15 K48396 4" Amber Led Lamp .......................................................................................................... 4
16 K48397 Rubber Gromet ................................................................................................................. 8
17 W-518 Hex Nut - 3/4 ..................................................................................................................... 2
18 W-527 Lockwasher - 3/4 ............................................................................................................... 2
19 W-539 Flatwasher - 1/2 ................................................................................................................ 8
20 K50112 Bale Spike ........................................................................................................................ 3
21 W-519 Nut - 7/8 ............................................................................................................................ 6
To Next Page
