16K PLUS October 2019 9-29
Final Assembly
Item Part No. Description Qty
1 10369 Chain - 3/8 x 8Ft Lg .......................................................................................................... 2
2 10662 Grab Hook - 3/8 Chain ...................................................................................................... 2
3 10677 Twin Clevis ....................................................................................................................... 2
4 10066 Hex Bolt - 5/8 x 8 Lg GR8 ................................................................................................. 1
5 10142 Draw Bar Hitch Plate ......................................................................................................... 2
6 10247 Klik Pin - W/Chain+Cotter - 1/4 x 1 3/4 Lg ........................................................................ 1
7 10313 Spacer Bushing - 1 1/2 OD x .375W ................................................................................. 1
8 11310 Alignment Arm End - Lt ..................................................................................................... 1
9 11319 Alignment Arm End - Rt .................................................................................................... 1
10 11724 Forklift Tooth - 8 x 84 ........................................................................................................ 2
11 C15768 Hex Jam Nut - 1 1/4 .......................................................................................................... 1
12 C17295 Locknut - 5/8 Nylon Insert ................................................................................................. 1
13 C33957 Carriage Bolt - 3/4 x 3 Lg .................................................................................................. 2
14 K45448 Hitch Bolt ........................................................................................................................... 1
15 K45683 Fork Retainer Block ........................................................................................................... 2
16 P61D20 Hex Nut - 1 1/4 .................................................................................................................. 1
17 S32590 Hex Bolt - 3/4 x 7 GR8 ...................................................................................................... 4
18 S34182 Washer - 1 9/32 ID x 2 1/2 OD .......................................................................................... 2
19 W-518 Hex Nut - 3/4 ..................................................................................................................... 6
20 W-527 Lockwasher - 3/4 ............................................................................................................... 6
21 W-541 Washer - 2 OD x .813 ID ................................................................................................... 4
K56033 String Saver (Not Shown)
Part will help to protect strings when Stacking 4X4 bale off string.
Short Bale Brackets (Not Shown)
12304 Bracket Rear ........................................................ 2
12305 Bracket Front ........................................................ 2
