16K PLUS October 2019 9-49
Hydraulic Brake Assembly
Item Part No. Description Qty
1 K50963 Connector - 3/8 MJIC x 3/8 Female BSPP ........................................................................ 4
2 S29967 Elbow - 90 - 9/16-18 MJIC x 9/16-18 FJIC swivel .............................................................. 7
3 C14901 Tee - (2)9/16-18 MJIC x (1)9/16-18 FJIC - M-F-M .............................................................. 3
4 C-4403 Tee - (2)9/16-18 MJIC x (1)9/16-18 FJIC - M-M-F .............................................................. 1
5 D17843 Hyd Hose - 1/4 x 40 Lg w/ 9/16-18 FJIC swivel ends ........................................................ 1
6 C26340 Hyd Hose - 1/4 x 252 Lg w/ 9/16-18 FJIC swivel ends ...................................................... 1
7 K50954 Brake Coupler - Female - 08 (1/2 inch) M18 x 1.5 Thread ................................................. 1
8 K51052 Bonded Seal - 18mm Male DIN (9500-18mm) ................................................................. 1
9 K50988 Brake Hose - 3/8 x 78 Lg w/ M18 x 1.5 Male DIN x 9/16-18 FJIC ...................................... 1
10 K50825 Bulkhead Mount ................................................................................................................ 1
11 S42307 Pressure Reducing Valve................................................................................................... 1
12 K50989 Mount Plate ....................................................................................................................... 1
13 C15348 Connector - 3/4-16 MORB x 9/16-18 MJIC ....................................................................... 3
14 C14835 Hyd Hose - 1/4 x 36 Lg w/ 9/16-18 FJIC swivel ends ........................................................ 2
15 K50993 Hyd Hose - 1/4 x 28 Lg w/ 9/16-18 FJIC swivel ends ........................................................ 2
16 K50962 Bulkhead - 9/16-18 MJIC .................................................................................................. 1
17 N42510 Locknut - 1/4 Centre Lock ................................................................................................. 4
18 S-1198 Flatwasher - 1/4 ................................................................................................................ 4
19 W-1540 Hex Bolt - 1/4 x 2 Lg.......................................................................................................... 2
20 W-469 Hex Bolt - 1/4 x 3/4 Lg....................................................................................................... 2
To Next Page
