Operation
5-46 October 2019 16K PLUS
Menu Screens - Continued
Adjust Menu - Continued
Backlight Menu
• Backlight: Adjusts how bright or dark the screen is.
Note: This parameter can also be adjusted by pressing the DOWN key when in the Auto screen.
Speed Adjustments
• Hitch: Adjusts how fast the hitch moves inline and offset.
• Loader Up: Adjusts how fast the loader moves up.
• Loader Down: Adjusts how fast the loader moves down.
• Alignment Arms: Adjusts how fast the alignment arms open or close.
• Auto Power Slide Back Min: Used to ne tune the operation of the Power Slide in Auto screen.
Note: The purpose of this procedure is to nd the minimum current (in Milliamps) required to just begin
opening the power slide valve. Once this variable is set, it should not be adjusted. If more power
is needed to begin pushing bales back in the Auto screen, adjust the “Initial Power Slide Force”
parameter in the Power Slide Push Back menu.
To set this parameter, use the following steps:
Warning: Keep all people clear of the machine while performing this procedure
1. Change the operation screen to Manual Load.
• Observe which buttons on the joystick control the “Slide Back” and “Slide Return”.
• Move the power slide up on top of the bed where it is easily observed.
2. Enter the “Speed Adjustments” menu and select the “Manual Load Power Slide Return” parameter.
• Record the value of this parameter for future use.
3. Set the value of “Manual Load Power Slide Return” to the minimum value.
• Press the “Slide Return” button on the joystick. If the power slide begins to move, use the minimum value
for “Auto Power Slide Back Min”.
• If the power slide does not move, hold the “Slide Back” button on the joystick while pressing the UP key to
raise the value of “Auto Power Slide Back Min”.
• Record the value of “Manual Load Power Slide Return” when the power slide rst begins to move.
4. Return the value of “Manual Load Power Slide Return” to that recorded in step 2.
5. Set the value of “Auto Power Slide Back Min” to the value found in step 3.
• Auto Power Slide Back Max: In the AUTO screen, adjusts the maximum speed of the power slide in Auto Mode.
• Auto Power Slide Return: Adjusts the maximum speed the power slide will return in Auto screen.
• Manual Load Power Slide Back: Adjusts the maximum speed the power slide pushes back in the Manual Load
screen.
• Manual Load Power Slide Return: Adjusts the maximum speed the power slide returns in the Manual Load screen.
To Next Page
