Motion Control Engineering Nidec iControl User Manual

4-24 Manual # 42-02-2223
Final Adjustment
Table 4.1 Floor Offset Calibration Record
Floor
Car Above/
below landing
Fractional
inch
Decimal
inch
Floor
Car Above/
below landing
Fractional
inch
Decimal
inch
30 60
29 59
28 58
27 57
26 56
25 55
24 54
23 53
22 52
21 51
20 50
19 49
18 48
17 47
16 46
15 45
14 44
13 43
12 42
11 41
10 40
939
838
737
636
535
434
333
232
131
Table 4.2 Fractional to decimal inch conversion
Fractional in. Decimal in. Fractional in. Decimal in.
1/32 .031 9/32 .281
1/16 .063 5/16 .313
3/32 .094 11/32 .344
1/8 .125 3/8 .375
5/32 .156 13/32 .406
3/16 .188 7/16 .438
7/32 .219 15/32 .469
1/4 .250 1/2 .500
