1-3
General Description
iControl AC
1
• Load weighers (optional)
• Rope Tension (LW-EMCO)
• Isolated Platform (LW-MCEIP)
• Cross Head Deflection (K-Tech International)
Figure 1.2 Single Car Component Assembly Illustrations
Group Dispatching
For multiple car installations requiring centralized dispatching and parking control:
• iCentral: Separate enclosure for complex dispatching requirements, destination based dis-
patching, security system interaction, groups to 15 cars (maximum 8 cars with destination
dispatching)
• Local: Groups to 6 cars with one car providing dispatching for the others. A central inter-
connect box is used for hall call risers and inter-car communications.
• iCentral backup: A second iCentral unit may be used or dispatching may be assumed by
one of the cars in the elevator group.
• Local backup: Dispatching assumed by a different car in the elevator group.
iAC Controller
iLink cartop box
iLand Compact landing system
