2-22 Manual # 42-02-2223
Construction Mode
TORQMAX F5 v3.xx Home Screen
The home screen provides a split menu with basic diagnostics. The F2 hot key accesses the diag-
nostic menus. The F3 hot key accesses the programming menu. The F4 hot key accesses the lan-
guage settings
Languages
The LCD Keypad supports seven languages:
At the Home screen, selecting the F4 hot key will take you directly to the language settings.
Programming Menu
The programming menu is where all manual parameter adjustments are made. At the Home
screen, selecting the (F3) hot key will take you directly to the programming menu. The menu
contains the following groups:
Diagnostic Screen
The LCD operator has split-view diagnostic screens. The diagnostics are grouped together
which makes it easier to view several related parameters. At the Home screen, selecting the (F2)
hot key will take you directly to the diagnostic menu. A fault log can be accessed on the last
diagnostic screen. To access: Home > Diag > Prev.
Parameter Adjustment
When adjusting a parameter, press the ENTER key to access Edit Mode. Parameters values can
only be changed in Edit Mode.
• Up/Down - Can be used to increment or decrement the number. Press the ENTER key to
save the change.
• F4 Hot key (NUM) - Pressing the F4 key in Edit Mode allows a user to adjust each place-
holder value. The other Hot keys change the placeholder or add a decimal point. Press
ENTER key to save the changes.
• >> Used to move placeholder for adjustment.
• . Inserts decimal point.
• <- Used as a backspace to move placeholder for adjustment
• + - Used to change the sign of the value.
English Spanish French Portuguese
Italian German Russian
Operator System (OS) Basic Setup (US) Inputs (LI)
Motor Data (LM) Encoder Data (LE) Machine Data (LN)
Speed Profile (LS) Tune Parameters (LL) Control Setting (LC)
Timer Parameters (LT) Positioning Parameters (LP) Special Functions (LX)
Configuration Handling (CH) Analog I/O (LA) Outputs (LO)
Diagnostic Parameters (DG) Field Bus Configuration (FB) Terminal Slowdown (TS)
