Adjusting Leveling and Final Stop
iControl AC
4
Ride Quality
If you are experiencing a ride sensation that is not exactly an oscillation, but might be described
as a rough texture:
For a TORQMAX F5 Drive, consider the following:
LC03 Kp Speed Accel
LC04 Kp Speed Decel
•LC08 Ki Speed Accel
•LC09 Ki Speed Decel
•LC25 Kp Speed High
LC41 System Inertia
LC42 FFTC Filter
•LC43 FFTC Gain
•LC44 Torque Cmd Filter
For a Magnetek drive, consider the following:
A1 - Response
A1 - Gain Reduce Mult
•A1 - Gain Chng Level
•C1 - Hi/Lo Gain Src
•A1 - Inertia
D1 - Est Inertia
The speed control loop gains may not be adjusted properly. Please refer to the Magnetek
Elevator Drive Technical Manual.
Motor shaft encoder may not be mounted securely, causing bouncing or slight variation in
speed feedback once every revolution. On a geared machine, the coupling used between
the tach or encoder and the motor can also be a source of vibration. In both cases, the
problem is visible by looking at the AC-coupled encoder speed signal on iBox test point
STP2 (with the Virtual Oscilloscope Test point 2 set to Speed Feedback). You may see the
vibration frequency increase and decrease with car speed. This is absolute proof of a
mechanical problem with the speed transducer. Electrically induced oscillations will be
characterized by a frequency that is constant (does not change significantly with speed).
If the above steps do not resolve the vibration, the motor may not have been trimmed to
the machine properly. Use a dial indicator to check alignment of motor and machine.
