2-31
Setting Initial Operating Parameters
iControl AC
2
Initial Controller Settings, HPV 900 S2
Configuration > Brake > Timer tab
• Pick delay = job specific - initially set to 1.0
• Speed pick delay 1 = job specific - initially set to 1.75
• Speed pick delay 2 = job specific - initially set to 0.75
• Contactor drop delay = 1.1
Configuration > Pattern > Common
• Lag delay = drive tuning specific - initially set to 0.3
• Leveling distance = drive tuning specific - initially set to 2.0
Configuration > Drive > General
• Normal rate limited stop = drive tuning specific - initially set to 7.0
•Drive type =HPV900
Initial Controller Settings, Quattro PM
• Configuration => Drive => General => Options
• Drive type: Quattro
• Drive interface: Analog
• Configuration => Drive => General => System
• Normal rate limited stop < drive tuning specific – initially set to 2.0>
• Configuration => Drive => General => Speed Reference
• Reference type: Tachometer
• Configuration => Brake => Control => Timer
• Pick delay < job specific – initially set to 1.5>
• Speed pick delay 1<job specific – initially set to 2.25>
• Speed pick delay 2<job specific – initially set to 0.75>
• Configuration => Pattern => Common => General
• Lag delay < drive tuning specific – initially set to 0.3>
• Configuration => Pattern => Common => Leveling
• Level distance < drive tuning specific – initially set to 2.0>
Initial Drive Settings, HPV 900 S2
Verify the following Magnetek parameters are set as indicated before startup. With the excep-
tion of the parameters listed below, verify that the drive parameters are set to drive default Eng-
lish values. A list of parameters is included in the Reference Section of this user guide.
Note
Verify/Modify A5 Motor ID before changing any other parameters. This parameter determines
the items visible in the menus.
A1 Drive Menu
• Contract Car Spd = job specific
• Contract Mtr Spd = job specific
