4-56 Manual # 42-02-2223
Final Adjustment
Before Release to Passenger Operation
Before the elevator can be turned over to normal passenger use, it is important that no
safety function or circuit remains bypassed. Items to check include, but are not limited to:
• All safety switches set to the OFF position
• No jumper between SB and 3 (iBox)
• No jumper between SAFH and 3 (iBox)
• Learn and Fault/Function switches set to OFF (iBox)
• No jumper between Gov and 3 (iBox)
• Pattern Scaling set to 100% (Pattern screen/Common tab)
If this is a local car (part of a group), the “Car identifier” parameter, on the Configuration > General >
General tab, must be set so that the Group controller can identify the car to which it is communicating.
Initially the Car identifier is defaulted to 1. The Car Identifier range is from 1 to 20. The Car identifier for
each car in a Group must be unique (no duplicates).
