Motion Control Engineering Nidec iControl User Manual

3-8 Manual # 42-02-2223
Inspection Mode
Verifying Door Operation
1. Verify that door related options required for this job are checked on the iView Safety
screen.
• Top Access Landing
• Top Access Rear
• Bottom Access Landing
• Bottom Access Rear
•No Main String
•No Main String Rear
• Front Door Close Contact
• Rear Door Close Contact
• Rear Doors
•Freight Door Option 1
• Door Position Monitor
2. Simulate opening the front car gate by removing the wire from the GS terminal on the
iBox.
• The iBox status LED “Doors Locked” will turn Off.
3. Reconnect the GS terminal.
4. Run the elevator up or down at inspection speed. Remove the DLAT (Door Lock Access
Top) input.
• The elevator should immediately stop.
• The Door Locked status LED will turn Off.
5. Reconnect the DLAT input. Repeat Step 4 for the DLAB input.
6. Reconnect the DLAB input. Repeat Step 4 for the DLMS input.
7. Reconnect the DLMS input.
8. Run the elevator at inspection speed. Move the Car Door Bypass switch to BYPASS.
• The elevator should immediately stop since the door lock cannot be bypassed while on
Machine Room Inspection.
9. Move the Car Door Bypass switch back to Off.
Verifying the Safety Configuration
Verify that safety options required for this job are checked on the iView Safety screen. Any
options that are checked, but not operational, will require a jumper to allow the car to operate
on Inspection (inputs must be high).
