2-33
Setting Initial Operating Parameters
iControl AC
2
C3 Logic Outputs Menu
Logic Output 3 (TB1-15 = Speed Reg Rls
Logic Output 4 (TB1-16 = Ramp Down Ena
Relay Coil 1 (TB2-27/28/29) = Ready to Run
C4 Analog Outputs Menu
Logic Output 1 (TB2-8 = Speed Command
Initial Drive Settings, Quattro PM
•A1 Drive Menu
Contract Car Spd <job specific>
Contract Mtr Spd <job specific>
Encoder Pulses <job specific>
Serial Cnt / Rev <job specific>
•A5 LS Pwr Convert Menu
Input L-L Volts <job specific>
•A6 Motor Menu
Rated Mtr Power <job specific>
Rated Mtr Volts <job specific>
Rated Motor Curr <job specific>
Motor Poles <job specific>
Rated Mtr Speed <job specific>
Verify D Axis Induct and Q Axis Induct are between 5 and 40 mH.
C1 User Switches Menu
Spd Command Src: Analog Input
Cont Confirm Src: External TB
Motor Ovrld Sel: Fault at Stop
•Pre-Torque Source: Analog Input
Ramped Stop Sel: Ramp On Stop
Ramp Down En Src: Run Logic
C2 Logic Inputs Menu
Logic Input 6 (TB1-6): No Function
Logic Input 7 (TB1-7): No Function
Logic Input 8 (TB1-8): No Function
•C3 Logic Outputs Menu
Relay Coil 1 (TB2-1/3/5): No Fault
Relay Coil 2 (TB2-8/10/12): Speed Reg Rls
