Construction Mode
• Encoder Pulses = job specific
• Serial Cnts/Rev = job specific (PM only)
• Contact Flt Time = 0.75
A2 S-Curves Menu
•Accel Rate 0 =7.99
• Decel Rate 0 = 7.99
• Accel Jerk In 0 = 0.00
• Accel Jerk Out 0 = 0.00
• Decel Jerk In 0 = 0.00
• Decel Jerk Out 0 = 0.00
A4 Power Convert Menu
• Input L-L Volts = job specific
A5 Motor Menu
• Motor Id = Select 4 Pole, 6 Pole, or PM
• Rated Mtr Power = job specific
• Rated Mtr Volts = job specific
• Rated Excit Freq = job specific
• Rated Motor Curr = job specific
• Motor Poles = job specific
• Rated Mtr Speed = job specific
• D Axis Induct = 5 to 40 mH
• Q Axis Induct = 5 to 40 mH
C1 User Switches Menu
• Spd Command Src = Analog
• Run Command Src = Analog
• Encoder Select = job specific (PM only)
• Cont Confirm Src = External TB
• Ramped Stop Sel = Ramp On Stop
•Ramp Down En Src =Run Logic
• Motor Ovrld Sel = Fault At Stop
•Pre-Torque Source =Analog
C2 Logic Inputs Menu
• Logic Input 4 (TB1-9) = NC Ctct Cfirm
• Logic Input 5 (TB1-10) = No Function
• Logic Input 6 (TB1-11) = No Function
• Logic Input 7 (TB1-24) = No Function
• Logic Input 8 (TB1-25) = No Function
• Logic Input 9 (TB1-26) = No Function
