2-30 Manual # 42-02-2223
Construction Mode
Figure 2.5 Magnetek Keypad Overview
Magnetek Drive Operation Overview
Menus, sub menus, and parameters may be accessed while the drive is running. Some parame-
ters may not be changed while the drive is running. For these parameters, the word “LOCK-
OUT” appears.
Operator LEDs indicate the status of the drive, generally including:
• Ready: Ready but not actually providing current to the motor.
• Run: Providing current to the motor.
•User: Selected via Logic Outputs C3 submenu.
• Fault: Drive has declared a fault.
• Torque Limit: The drive has reached its torque limit. See drive manual.
• Sub Menu: A sub menu has been accessed.
• Data Entry: A parameter value has been accessed.
Select Menu
Select Digit
Enter Submenus
Select Parameter
Change Value
ENTER
Move Up a Level
ESCAPE
Display 1 D0
Elevator
Data D1
Power
Data D2
LS Power
Data D3
(quattro)
Adjust A0
Drive A1
S-Curves A2
Multistep Ref A3
Power Convert A4
(MS power for Quattro)
LS Power Convert A5
(quattro only)
Motor A5 (A6 for
quattro)
Configure C0
User Switches C1
Logic Inputs C2
Logic Outputs C3
Analog Outputs C4
Utility U0
Password U1
Hidden Items U2
Units U3
Ovrspeed Test U4
Restore Dflts U5
Drive Info U6 (MS info for quattro)
Hex Monitor (LS info for quattro) U7
Language Sel U8 (Hex Montitor for quattro)
Basics U9 (not for quattro)
Rotor Align U10 (quattro only)
Time (Auto Tune for quattro) U11
Faults F0
Active Faults F1
Fault History F2
Sorted History F3
Reset Faults F4
Changes are saved only after ENTER is pressed.
Some parameters cannot be changed while the elevator is operating.
Magnetek Menus & Submenus
