6-61
iControl Messages
iControl AC
6
Rear Door Close Fault Recovery Failure, R DR CLS FLT REC FAIL
Description: Door Close Fault Recovery timer starts when Door Close Fault generated. When timer expires,
Door Close Fault cleared so doors again attempt to close (see Rear Door Close Fault). This is repeated num-
ber of times specified by Door Close Fault Recovery Attempts parameter. If doors have failed to close when
number of attempts equals recovery attempts setting, Rear Door Close Fault Recovery Failure generated.
Car Reaction: Car may not run until mode change detected or doors successfully closed via constant pres-
sure on Door Close Button.
Troubleshooting:
1. Door closed status determined by door close limit and door position monitor. Check wiring.
2. Check door close protection timer and number of closing attempts on Car Operation - Doors tab.
Rear Door Close Time-out
Description: Failure of rear door to close detected. Controller will attempt to close doors for a period of time
defined by Closing protection timer parameter (Door Motor Protection Timers). If timer elapses prior to doors
closing fully, event is generated.
Car Reaction: Doors reopen fully and again attempt to close.
Troubleshooting:
1. Door closed status determined by rear door close limit and rear door position monitor contact.
2. Check wiring of these signals.
3. Check Closing protection timer (iView Car Operation Configuration/Doors Tab/General Tab/Door Motor
Protection Timers).
Rear Doors Stopped, REAR DOORS STOPPED
Description: Door Stop button or Emergency Stop switch activated preventing door movement.
Car Reaction: Car is not allowed to move unless doors are fully closed.
Troubleshooting: Can be cleared by activation of Door Open or Door Close button or if car enters Inspection
or Fire Service mode, provided the Door Stop input is off.
Rear Door Contact Fault, REAR DOOR CONTCT FLT
Description: Faulty rear door contact (gate switch, door lock) detected. Detected when doors are in fully
open position and either gate switch contact is closed or doors appear to be locked.
Car Reaction: All car calls canceled and car removes itself from hall call service. Rear doors are not allowed
to close and car is not allowed to run.
Troubleshooting:
1. Check the rear door gate switch and door lock contact at the floor at which the car is located.
2. Check associated wiring for these signals.
Rear Door Open Button Bypassed, REAR DOB BYPASSED
Description: Rear door open button continuously activated for user-defined time and now bypassed accord-
ing to user setting. (iView/Car Operation/Doors/Advanced.)
Car Reaction: The rear door open button is rendered inoperative.
Troubleshooting:
1. Check corresponding input: Rear Door - Open Button (Normally low).
2. Operation of door open button can be restored by setting Door open button bypass option to off
(unchecked) (Car Operation Configuration/Doors Tab/Advanced dialog).
Table 6.3 iControl Messages
