Troubleshooting
Software Version Query
Used by themselves (not in conjunction with another DIP switch as in Diagnostics), switches 1,
2, and 3 will separately display the board software version level (iControl only):
• Switch 1 ON will display the low version number on the first 8 LEDs (IO1 - IO8).
• Switch 2 ON will display the middle version number on the first 8 LEDs (IO1 - IO8).
• Switch 3 ON will display the high version number on the first 8 LEDs (IO1 - IO8).
The number is expressed in binary format with IO1 the least significant and IO8 the most signif-
icant value.
If you do a software version query, BE SURE to set the DIP switch rockers (1, 2,
3,4, 6, 7 back to OFF afterwards. OFF is their default.
Table 7. iControl Software Version Number Example
IO8=128 IO7=64 IO6=32 IO5=16 IO4=8 IO3=4 IO2=2 IO1=1 Value
S1 OFF OFF OFF ON OFF OFF OFF OFF 16
S2 OFF OFF OFF OFF ON OFF OFF OFF 8
S3 OFF OFF OFF OFF OFF OFF ON ON 3
Example software version: 3.8.16
