Motion Control Engineering Nidec iControl

6-96 Manual # 42-02-2223
Troubleshooting
ICE-IMP Main Processor Board
TORQMAX
Interface
RS 232 PC
Ethernet
3 = PC
Ethernet
2 = SYSTEM
Serial Hall
Call 1
Serial Hall
Call 2
Magnetek
Interface
IMP Flash
Switches:
INSPECTION
UP
ENABLE
DOWN
CONTRLR. STOP
CAPTURE
TEST
FAULT BYPASS
WRITE ENABLE
LEARN
C.DOOR BYPASS
H.DOOR BYPASS
Battery:
1/2 AA, 3.6V
Lithium
Test Points:
+1.5V
+2.5V
+3.3 B
+5V
DGND
+5V to power
supply shunt
R
i
b
b
o
n
c
a
b
l
e
t
o
O
n
b
o
a
r
d
Di
s
p
l
a
y
Programming
port, factory
use only
J
P
1
4
,
J
P
1
3
,
J
P
1
2
JP6
Ethernet
1 = LAN
JP1
Internal CAN
External CAN
AC 18V
JP8, JP16
Internal CAN
CAN Trmnate
