7-11
System Status Display
iControl AC
7
LCD Status Display
The LCD screen displays text messages advising of sys-
tem status. The second line of the display shows the mode
of operation (Passenger in the example) displayed in
rotation with any active status messages. Please refer to
“iControl Messages” on page 6-14 for description.
System Control Switches
The front panel system control switches allow you direct access to system functions including:
• Inspection: Switch used to place the car on Machine Room Inspection (Insp) or Normal
operation (Norm).
• Up: Push switch used to run the car up when the system is on Machine Room Inspection
and the Enable button is simultaneously pressed and held.
• Enable: Push switch used to run the car up or down when the system is on Machine Room
Inspection and the Up or Down button is simultaneously pressed and held.
• Down: Push switch used to run the car down when the system is on Machine Room
Inspection and the Enable button is simultaneously pressed and held.
• Controller Stop: Switch used to immediately remove hoist motor and brake power (Stop)
or apply power to those systems (Run).
• Capture: Switch used to place Car on Capture operation (On). While this switch is On, the
car will not respond to hall call demand or Parking.
• Test: Switch used to place the car on Test Mode operation (On).
• Fault/Function Bypass: Switch to allow specific faults and safety functions (as determined
by Keypad/LCD settings) to be bypassed. Car must be in Test mode.
• Write Enable: (Factory only) Switch used to allow special data to be saved (On).
• Learn: Switch used to confirm intended Learn operation. The learn procedure must be
selected. For Hoistway Learn, the car must be on Inspection mode. For Terminal Switch
Learn, the car must be on Test mode.
• Car Door Bypass: Switch used to bypass the car door electric contacts (Bypass position).
When set to Bypass, the car will run only on Inspection mode. The ability to set this bypass
must be enabled at the factory and is only available if allowed by safety regulations in your
area. Check the iView Safety Configuration screen to see if the feature is enabled in your
installation.
@003 s 015 FG RO L03
Passenger
Ofpm
2:26:22AM
11/30/2003
Car Mgmt
