8-29
iView Windows and Tabs
iControl AC
8
Table 8.7 Controller - Setup Tabs
Tab Content
Brake Calibrate the brake voltage settings (see page 2-29).
Counterweight Learn the position where counterweight is adjacent to the car (see page 3-11).
Drive Learn the values for the Drive Offsets (see page 2-34).
Floor Heights Learn the absolute floor positions (distance to each floor from the lowest landing). Also
used to assist in measuring and entering the floor offsets (deviation of floor magnet
position from actual floor stopping position) (see page 4-2, page 4-25).
Load Weigher Learn the car empty and full load weights (see page 4-32).
Safety Verify that the configurations of the main and safety processors match. Perform the
Inventory learn procedure.
Terminal Switches Learn the speeds and positions of the normal and emergency terminal switches (see
page 4-8.
Table 8.8 Controller - Miscellaneous Dialogs/Controls
Tab Content
Call
Registration
Allows you to register car and hall calls. This control is accessed by clicking the Call
Registration button on the button bar.
Firmware Update Guides you through the process of updating iControl firmware. This control is accessed
by selecting Firmware Update from the File menu.
Refresh Updates the information displayed on iView windows and tabs. This control is accessed
by clicking the Refresh button on the button bar.
