Software Test Point Signals
iControl AC
9
Pattern (Interpolated) Interpolated (smoothed) pattern signal.
Pattern (Phase) The numbers displayed represent segments of the speed profile.
Please refer to “Shaping the Speed Profile” on page 4-12.
0 = Idle
1 = Initial Jerk
2 = Acceleration
3 = Low Roll Jerk (during acceleration, high speed is reached)
4 = Peak (High Speed)
5 = High Roll Jerk (during acceleration, high speed not reached)
6 = High/Low Roll Jerk (during deceleration)
7 = Deceleration
8 = Flare Jerk (transition from deceleration to leveling)
9 = Approach Jerk (transition from deceleration to leveling)
10 = Leveling
Pattern (Raw) Raw pattern signal.
Pattern (Region) The numbers reflect a simplified representation of the speed
profile in comparison to Pattern (Phase).
0 = Idle 3 = Deceleration
1 = Acceleration 4 = Flare
2 = Peak 5 = Leveling
Pattern (Slew Limited) Slew rate limited pattern signal.
Position Bit This signal represents car position/motion. It is abstracted from
the motor velocity encoder or tach signal. The signal toggles low
or high with every 32-inches of motor travel. Increasing fre-
quency = increasing rate of position change.
Pre-Run Status High = Pre-energizes motor field as doors are closing and
demand occurs.
Pretorque (Command) This is the actual pretorque signal sent to the drive and used to
pretorque the motor. This is filtered representation of the raw
pretorque “demand” signal, captured as the doors close and
used to pretorque the motor as needed depending on the weight
in the car.
Pretorque (Raw) This is a representation of the raw pretorque “demand” signal. It
will react to car load changes (i.e., doors open, passengers load-
ing/unloading).
SCR Current Sensor Offset Status High = SCR current sensor signal offset positive.
SCR Intg Offset Status High = SCR integrator signal offset positive.
Speed Bit When the car is still, this signal is high. When the car is travel-
ling at a rate in excess of 40fpm, this signal is low.
Speed Feedback Filtered speed feedback signal. Please refer to “Following Error
Margin” on page 2-49.Please refer to “Tach Error Tripping
Threshold Adjustment” on page 2-50. Please refer to “Empty Car
Tests” on page 3-13. Please refer to “Verifying a One Floor Run”
on page 4-4. Please refer to “Setting Pattern Parameters” on
page 4-14. Please refer to “Tach Error Tripping Threshold Adjust-
ment” on page 4-40.
Sufficient Field Status High = sufficient motor field current has been achieved. Differ-
ent percentage of forcing, depending on mode. Inspection =
60% of forcing. Other, 80% of forcing.
Synthetic Signal Speed signal synthesized from armature voltage and current.
