TORQMAX F5 Drive v3.xx Parameters Table
iControl AC
9
TORQMAX F5 Drive v3.xx Parameters Table
Enter the settings you make while adjusting into the Field column of the following table.
Table 9.5 TORQMAX F5 Drive, v3.21 LCD Parameter Settings
Para. Name Setting Num Range Units Default
Field
Setting
WARNING: Do not change drive parameters while the elevator is running. Incorrect drive
parameter values can cause erratic operation.
WARNING: Parameters with an asterisk (*) must be set correctly for your specific motor /
machine / job. Refer to the adjustment manual for detailed information.
US Basic Setup Parameters
US02 System Units
m/sec
ft/min
0
1
- ft/min ft/min
1
US03 Motor Type
Induction Geared
Induction Gearless
PM Synchronous Geared PM
Synchronous Gearless
0
1
2
3
--
Induction
Geared
US04 Control Type
Digital Speed Selection
Binary Speed Selection
Absolute Analog Speed
Bi-Polar Analog Speed
Serial Spd DIN66019, Serv.49
Serial Spd DIN66019, Serv.50
Serial Binary Spd DIN66019,
Serv.50
0
1
2
3
4
5
6
--
Binary
Speed
Selection
3
(if analog
interface)
5
(if serial
interface)
US05
Load
Configuration
Not Configured
Configuration OK
Write Config. to Drive
Read Config. from Drive
Write Config. to Flash
Read Config. from Flash
Write Config. to SD Card
Read Config. from SD Card
Create OEM Defaults
Restore OEM Defaults
Restore KEB Defaults
0
1
2
3
4
5
6
7
8
9
10
--
Not
Configured
US06 Contract Speed
m/s
ft/min
0
1
0-1600 ft/min ft/min
LI Input Parameters
LI01 Type of Input
PNP
NPN
0
1
--PNP
LI02
Digital Input
Filter
10-100 msec 20
LI03
Speed Input
Decoding
(not used)
US04 Control Type = Binary
Speed Selection
0
1
2
3
--
(0); B(Level
-Correct -
Inspection)
US04 Control Type = Digital
Speed Selection
0
4
8
+D(Level
-Correct- High
- Inspection)
