Accessories 2 - 11
2. Align the lip of the cup with the slot on the front of the cradle. Ensure that the cup is positioned within the
Slot Alignment Tabs.
Figure 2-11
Five Slot Universal Charge Only Cradle Cup Installation
3. Slide the lip into the slot and rotate the cup until it is flat on the cradle base.
4. Using a Phillips screwdriver, secure the cup to the charger base using the two screws provided with the
cup.
Figure 2-12
Securing Cup to Base
5. Each slot on the Cradle Base must have a cup installed.
6. Repeat for each additional cup.
