Users Guide ValueJet 1614
55 AP-75790 Rev 1.4 -22/02/2011,
Step 7 : Perform the initial adjust print.
Press the [Enter] key on the operation panel.
± The operation panel displays "Feed Length: 250 mm".
Notes
The length that the media is fed for initial adjustment printing is normally set at 250 mm.
If you make the feeding length longer, the accuracy of the Media feed compensation improves.
If you want to change the feeding length, press the [+] key or [] key and change the set value.
Press the [Enter] key on the operation panel.
± The operation panel displays "Printing".
± Start Initial adjustment printing.
î
ïï
N° Name
1 Feed length
2 Media feeding direction
± When the initial adjustment printing is complete, the printer enters the normal status
After the initial adjustment printing, cut the media. Refer to: Cutting media
Step 8 : Measure the distance between two + signs in the initial adjustment print using a measurement
tool, such as a ruler.
Step 9 : Set up Initial Adjust Change.
Press the [+] key or [] key to select "PF2: Initial Change".
Press the [Enter] key on the operation panel.
± The operation panel displays "Init: 250.0/250mm".
Press the [+] key or [] key and enter the measured value in step 3.
Press the [Enter] key on the operation panel
± The initial adjustment value is saved.
± The operation panel displays "PF2: Initial Change".
To Next Page
