Cassette interface
The cassette interface is divided into the following main parts:
1. Attachment unit.
2. Motor unit.
Attachment unit
1. Attach claw.
2. Suction cups.
3. Steering blocks.
4. Circuit board.
Figure 3-12. Cassette interface main parts.
1
2
Figure 3-13. Attachment unit main parts.
1
2
4
2
3
3
