Routine Maintenance MY500 JetPrinter MYDATA
5 - 18 Rev. 0003 2008-06 P-030-0014-EN – Service Manual
Be careful not to loose the spring, highlighted in Figure 5-18, when you take
a new ejector out of its packing.
In a new ejector there is a conditioner that must be removed before it can used
in production. After having changed the ejector, and inserted a cartridge,
always do an Extended Purge. Hereby the conditioner will be replaced with
fresh solder paste.
Figure 5-18. Ejector spring.
