Remote control 14-35
14.8 Sweep
Mode
commands
sequence
example
This is the sequence used by the PMM Emission Suite when a scantable is run, in
the “conducted” range (from 9 to 11 MHz).
Example
Command sent Reply received Description
#?IDN*
Queries information about model, release and date of the firmware
IDN=9010/30P - 2.56 12/01/15
It is a 9010/30P with its FW
It is used to check congruencies, frequency limits, and all the related
characteristics
#?BCD*
Queries if a fibre optic device, like 9060 or 9180 is connected to the
basic unit
BCD=Off;30P
There are not fibre optic devices connected
In case we know if the unit for high frequencies is connected and ready
#?S/N*
Queries the serial number
S/N=010WX00610
Serial number
#?MIL*
Queries if MIL option is active
MIL=OK
MIL option installed
Extra RBW available
#?CRA*
Queries if RMS-AVG optional detector is active
CRA=OK
RMS-AVG active
#SCFA -1*
Correction factors, if present, deactivated
CFA=OK (OFF)
Important. Can be previously stored and activated by panel of from a
previous setting
#SDIS120;120*
Sets display reference and dynamic. No effect on the measure
DIS=OK
Ack
#SPLMOFF*
Switches off the internal pulse limiter
PLM=OK
Pulse limiter off
#STGSOFF*
Switches off the internal TG. Could be on from a previous setting
TGS=OK
ack
#?BAT*
Reads the battery level. Important if it is too low…
BAT=7.66;1
It is 7.66V and it is a new reading
#S3PRC*
sets the unit in the bands A and B for conducted
3PR=OK
ack
#SSFD
9000000;11000000;5000;P;2;4;10;OFF;OFF;0*
Sweep
Binary data reply
Measurements data
#?UHT*
Queries the hold time
UHT=2.0ms
Applied hold time
To Next Page
