1-2 General Information
1.4 Instrument Items
PMM 9010 includes the following items:
• EMI Receiver from 10 Hz up to 30 MHz
• BP-02 Li-ion battery pack;
• External power supply/battery charger;
• Flexible black cover/accessories holding;
• BNC-BNC coaxial cable 2m length;
• RS232 cable, 2m;
• USB cable, 2m;
• Operating manual;
• PMM 9010 Utility Software on Software Media;
• Certificate of Compliance;
• Return for Repair Form.
1.5 Optional
accessories
PMM 9010 can be used with several optional accessories, the most
common being the following:
• PMM 9030 EMI receiver 30 MHz - 3 GHz;
• PMM 9060 EMI receiver 30 MHz - 6 GHz;
• PMM 9180 EMI receiver 6 GHz - 18 GHz;
• 9010-BTA Serial Bluetooth Adapter;
• Single Channel Click option;
• PMM 9010-RMA Rack Mount Adapter for Rack 19”
• L2-16B: Two lines, Single phase, 16A LISN, (50Ω//5 Ω+50μH);
• L3-32: Four lines, 3-phase, 32A LISN, (50Ω//5 Ω+50μH);
• L3-64: Four lines, 3-phase, 64A LISN, (50Ω//5 Ω+50μH);
• L3-64/690: Four lines, 3-phase, 64A - 690Vac
LISN, (50Ω//5 Ω+50μH);
• L3-100: Four lines, 3-phase, 100A LISN, (50Ω//5 Ω+50μH);
• L1-150M: Single line LISN, 150A (50Ω//1 Ω+5μH);
• L1-150M1: Single line LISN, 150A (50Ω//1 Ω+5μH);
• L1-500: Single line LISN, 500A LISN, (50Ω//5 Ω+50μH);
• L3-500: Four lines, 3-phase, 500A LISN, (50Ω//5 Ω+50μH);
• L2-D: Delta LISN for telecom, 2A, 150Ω
• SBRF4 RF Switching Box (Switching Box for LISNs and Loop
Antennas)
• LISN Service Kit (AC-BNC adapter for LISNs verification and
calibration)
• SHC-1/1000: 35 dB CISPR Voltage probe, 1500Ω;
• SHC-2/1000: 30 dB CISPR Voltage probe, 1500Ω;
• RA-01: Rod Antenna (10 kHz – 30 MHz);
1.6 Other accessories
Of course, the PMM 9010 can be used with other accessories available on
the market, like:
• LISNs, any type;
• Antennas and Loops;
• Near Field Probes;
• Various TEM/GTEM Cells;
• HXYZ 9170 Triple Loop Antenna
• GPIB to RS232 Adapter.
