11-6 PMM 9030/9060/9180 Frequency Extension
11.7 PMM 9060
Main Specifications
Table 11-2 lists the PMM 9060 performance specifications.
The following conditions apply to all specifications:
• thanks to its analogue+digital architecture, the PMM 9060 needs only
15 minutes of warm-up period before to operate in full-compliance
with specifications;.
• the ambient temperature shall be 0°C to 40°C
TABLE 11-2 PMM 9060 Main Specifications
Frequency range
Resolution
Frequency Accuracy
30 MHz to 6 GHz (CISPR-16-1-1 Full-Compliance)
100 Hz
< 2 ppm
RF input
VSWR
10 dB RF att.
0 dB RF att.
Attenuator
Preamplifier gain
Z
in
50 Ω, N fem.
< 1,2; <2 over 1 GHz;
<2; <3 over 3 GHz
0 dB to 55 dB (5 dB steps)
20 dB; 15dB above 1 GHz
Max input level
(without equipment damage)
Sinewave AC voltage
Pulse spectral density
137 dBuV (1 W)*
97 dBµV/MHz
Preselector
Four tracking filters;
Two bandpass filter
30,0 MHz to 72.0 MHz
72.0 MHz to 173,0 MHz
173,0 MHz to 416.0 MHz
416.0 MHz to 1 GHz
1 GHz to 3 GHz
3 GHZ to 6 GHz
IF bandwidth
6 dB bandwidth
CISPR 16-1-1 bandwidth (6 dB)
3, 10, 30, 100, 300 kHz, 1 MHz (Bimp)
120 kHz
(*) with MIN ATT ≥ 10 dB
