General Information 9-11
9.13 PMM 9010/60P
Main Specifications
Table 9-3 lists the PMM 9010/60P performance specifications.
The following conditions apply to all specifications:
• The ambient temperature shall be 0°C to 40°C
For what is concerning the specifications of the full compliance A
and B bands section refer to the specification of the 9010 in the
chapter 1.
TABLE 9-3 Main Specifications for CDE bands
Frequency range
Resolution
Frequency accuracy
30 MHz to 6 GHz
100 Hz
< 2 ppm
RF input
VSWR
10 dB RF att.
0 dB RF att.
Attenuator
Z
in
50 Ω, N fem.
< 1.2, <2.0 over 1 GHz
< 2.0, <3.0 over 3 GHz
0 dB to 55 dB (5dB steps)
Max input level
(without equipment damage)
Sinewave AC voltage
Pulse spectral density
PRF (CISPR 16-1-1)
137 dBµV (1 W)*
97 dBµV/MHz
≥ 10Hz
IF bandwidth
Standard 6 dB
CISPR 16-1-1 bandwidth (6 dB)
MIL-STD-461 (option)
3, 10, 30, 100, 300 kHz, 1 MHz
120 kHz
100 kHz, 1 MHz
Noise level
30 to 300 MHz < 10 dBuV (QP)
(120 kHz BW) < 7 dBuV (AV)
300 to 3000 MHz < 13 dBuV (QP)
(120 kHz BW) < 7 dBuV (AV)
3000 to 6000 MHz < 15 dBuV (QP)
(120 kHz BW) < 10 dBuV (AV)
Spurious response
< 10 dBµV, < 15 dBµV over 2 GHz
Measurement accuracy
(S/N > 20 dB)
30 MHz to 1 GHz ± 1,0 dB
1 GHz to 3 GHz ± 1,5 dB
3 GHz to 6 GHz ± 2,0 dB
Operating temperature
Power supply
0° to 40°C
10 - 15 Volt DC, 2,5A; Optional Li-Ion interchangeable
battery (8 h operations, typical)
Dimensions
235 x 105 x 335 mm
Weight
4.1 kg
(*) with MIN ATT ≥ 10 dB
