12-2 PMM 9010-RMA Rack Mount Adapter
12.4 PMM 9010-RMA
Main Specifications
Table 12-1 lists the PMM 9010-RMA specifications.
TABLE 12-1 Technical Specifications
Environment temperature
0° to 40°C
Rack unit
3U
Dimensions
483 x 410 x 132.5 mm (WxDxH)
Weight
5,5 Kg (without instruments)
12.5 PMM 9010-RMA Front view
Fig. 12-1 Front view
Legend::
- 1 – Holes Flanges used to fix the Rack Mount to the Rack
- 2 – Handles used to carry the Rack Mount
- 3 – PMM 9010 or 9010/03P/30P/60P window
- 4 – Milled knob used to fix the frontal panel to the Rack
- 5 – Cover for future implementation
