9010F Fast 15-3
15.1.2 Instrument Items
PMM 9010F includes the following items:
• EMI Receiver from 10 Hz up to 30 MHz
• BP-02 Li-ion battery pack;
• External power supply/battery charger;
• Flexible black cover/accessories holding;
• BNC-BNC coaxial cable 2m length;
• RS232 cable, 2m;
• USB cable, 2m;
• Operating manual;
• PMM 9010 Utility Software on Software Media;
• Certificate of Compliance;
• Return for Repair Form.
15.1.3 Optional
accessories
PMM 9010F can be used with several optional PMM accessories:
• 9010-BTA Serial Bluetooth Adapter;
• PMM 9010-RMA Rack Mount Adapter for Rack 19”
• L1-150M: Single line LISN, 150A (50Ω//1 Ω+5μH);
• L2-16B: Two lines, Single phase, 16A LISN, (50Ω//5 Ω+50μH);
• L3-32: Four lines, 3-phase, 32A LISN, (50Ω//5 Ω+50μH);
• L3-64: Four lines, 3-phase, 64A LISN, (50Ω//5 Ω+50μH);
• L3-100: Four lines, 3-phase, 100A LISN, (50Ω//5 Ω+50μH);
• L1-500: Single line LISN, 300A LISN, (50Ω//5 Ω+50μH);
• L3-500: Four lines, 3-phase, 300A LISN, (50Ω//5 Ω+50μH);
• SBRF4 RF Switching Box (Switching Box for LISNs and Loop
Antennas)
• SHC-1: 35 dB CISPR Voltage probe, 1500Ω;
• SHC-2: 30 dB CISPR Voltage probe, 1500
Ω;
• RA-01: Rod Antenna (10 kHz – 30 MHz);
• VDH-01: Van der Hoofden Antenna (20 kHz – 10 MHz);
• GPIB to RS232 Adapter;
• Triple Loop Antenna
15.1.4 Other accessories
Of course, the PMM 9010F can be used with other accessories available
on the market, like:
• LISNs, any type;
• Antennas and Loops;
• Near Field Probes;
• Various TEM/GTEM Cells
Be sure not to overload PMM 9010F: the input signal should not
exceed the maximum level indicated in the main specifications in
chapter 1.
Also do not apply any signal to RF generator output connector.
