General Information 9-5
9.7 PMM 9010/03P
Main Specifications
Table 9-1 lists the PMM 9010/03P performance specifications.
The following conditions apply to all specifications:
• The ambient temperature shall be 0°C to 40°C
For what is concerning the specifications of the A and B bands
section refer to the specification of the 9010 in the chapter 1.
TABLE 9-1 Main Specifications for C bands
Frequency range
Resolution
Frequency accuracy
30 MHz to 300 MHz
100 Hz
< 2 ppm
RF input
VSWR
10 dB RF att.
0 dB RF att.
Attenuator
Z
in
50 Ω, N fem.
< 1.2
< 1.2
0 dB to 50 dB (2dB steps)
Max input level
(without equipment damage)
Sinewave AC voltage
Pulse spectral density
137 dBuV (1 W)*
97 dBµV/MHz
PRF (CISPR 16-1-1)
≥ 10Hz
IF bandwidth
Standard 6 dB
CISPR 16-1-1 bandwidth (6 dB)
MIL-STD-461 (option)
3, 10, 30, 100, 300 kHz, 1 MHz
120 kHz
100 kHz, 1 MHz
Noise level
30 to 300 MHz < 8 dBµV (QP)
(120 kHz RBW) < 4 dBµV (AV)
Spurious response
< 15 dBµV
Measurement accuracy
S/N > 20 dB
± 1,0 dB
Operating temperature
Power supply
0° to 40°C
10 - 15 Volt DC, 2,5A; Optional Li-Ion interchangeable
battery (8 h operations, typical)
Dimensions
235 x 105 x 335 mm
Weight
4.1 kg
(*) with MIN ATT ≥ 10 dB
