Four Channels Click Meter Option A-C-5
A-C.2.8 Return for
Service
If the instrument should be returned to NARDA for service, please complete
the service questionnaire enclosed with the Operating Manual and attach it
to the instrument. To minimize the repair time, be as specific as possible
when describing the failure. If the failure only occurs under certain
conditions, explain how to duplicate the failure.
If possible, reusing of the original packaging to ship the equipment is
preferable. In case other package should be used, ensure to wrap the
instrument in heavy paper or plastic.
Use a strong shipping box and use enough shock absorbing material
all around the equipment to provide a firm cushion and prevent
movement in the shipping box; in particular protect the front panel.
Seal the shipping box securely.
Mark the shipping box FRAGILE to encourage careful handling.
A-C.2.9 Equipment
Cleaning
Use a clean, dry, non abrasive cloth for external cleaning of the equipment.
To clean the equipment do not use any solvent, thinner, turpentine,
acid, acetone or similar matter to avoid damage to external plastic or
display surfaces.
A-C.2.10 Equipment
ventilation
To allow correct equipment ventilation ensure that the vent grids on
the rear panel and on the bottom of the receiver are free by any
obstructing object.
A-C.2.11 Hardware
Installation
PMM 9010/Click4E Option is delivered from factory ready to use. Remove
the receiver from its cardboard shipping box, connect the power cord to the
mains and turn the rear power switch “ON”.
The PW Led lights up.
After having been switched ON, the PMM 9010/Click4E Option boots with its
internal BIOS and runs the firmware which manages the receiver.
At the beginning the instrument performs a diagnostic test to check if
everything is working properly.
The boot sequence is indicated by a fast blinking of the four front panel leds.
The intercommunication between the two units is done by connecting
the RS-232 Port of the 9010 to the RS-232 Port (to 9010) of the Click4E
Option with a standard serial cable (supplied with the receiver).
When the Optional Unit is ready (the PW led is blinking and L1, L2, L3 leds
are off) it is necessary to switch on the PMM 9010 receiver.
When the sequence is completed the PW Led on the Click4E Option
becomes green and the main screen shows the test results and the main
functional keys on the right of the LCD display: the receiver is now ready to
operate.
Connect the supplied RF Cable from the Output BNC of the Optional
Unit to the Input of the 9010 Receiver.
Connect the output of any LISN (or any other transducer) to the RF input of
the Optional Unit.
When using a PMM LISN, it is possible to control from the receiver the lines
of the LISN and automatically switch between them connecting a special
cable between the User Port of the receiver and the LISN remote control
input.
To switch OFF the unit move the main switch to “OFF” position.
