CHAPTER 3 SYSTEM DATA PROGRAMMING
– 102 – NWA-008853-001 Rev.3.0
97ch3001.fm
DESCRIPTION DATA
[North America/µ-law countries] [A-law countries]
Provide station to station transfer over CCIS. (1)
(2)
253
0: Available
E
CM42
T/R: Transmit/Receive
+: Gain
–: Loss
PATTERNS
2ND DATA
PAD DATA OF
B TRUNK
DTI/CCT (T/R)
[dB]
00
15
00 0/0
01 –2/–2
02 –3/–3
03 0/–6
04 –3/–8
05 +3/–3
06 –6/–6
07 –8/–8
08
15
Not Used
~
~
T/R: Transmit/Receive
+: Gain
–: Loss
PATTERNS
2ND DATA
PAD DATA OF
B TRUNK
DTI/CCT (T/R)
[dB]
00
15
00 0/0
01 –2/–2
02 –3/–3
03 0/–6
04 –3/–8
05 +3/–3
06 –6/–6
07 –8/–8
08
15
Not Used
~
~
CM08
END
JANUARY/31/2006
DIGITAL CCIS PROGRAMMING
