CHAPTER 3 SYSTEM DATA PROGRAMMING
– 117 – NWA-008853-001 Rev.3.0
97ch3001.fm
(7) Assign the CCH number to each CCH.
(8) Assign the CCH to each route.
(9) Assign a CIC to each voice channel trunk.
(10) Assign the CCH data.
Command Code 1st Data 2nd Data
06 Y=07 0 06 : CCH 0
1 07 : CCH 1
Command Code 1st Data 2nd Data
35 Y=91 10 0
: CCH 0
11 0
12 1
: CCH 1
13 1
Command Code 1st Data 2nd Data
30 Y=35 000 001 : CIC1
001 002 : CIC2
003 001 : CIC1
004 002 : CIC2
Command Code 1st Data 2nd Data
A7 Y=00 0 002
Common Signaling Channel assignment
1 005
A7 Y=01 0 00001
Originating Point Code assignment
1 00001
A7 Y=02 0 00010
Destination Point Code assignment
1 00020
A7 Y=06 0 0820
Office number assignment
1 0820
A8 00010 0 Destination Point Code to which a signaling
message is transferred.
00020 1
DIGITAL CCIS PROGRAMMING
