CHAPTER 3 SYSTEM DATA PROGRAMMING
ā 118 ā NWA-008853-001 Rev.3.0
97ch3001.fm
(11) Assign the route access data.
NOTE: The example shows:
8 22 XX...XX
Station numbers in distant PBX
Office number of distant PBX
LCR access code
Second dial tone will be heard after 8 is dialed.
8 will be added and sent to distant PBX.
Command Code 1st Data 2nd Data
20 Y=0 8 A126 : Access Code=8
8A Y=A000 0 4005 : Area Code Development Pattern No. 5
8A Y=4005 22 0000 : Route Pattern 000
25 0001 : Route Pattern 001
8A Y=0000 1 00010 : Trunk Route 10
8A Y=0001 1 00012 : Trunk Route 12
8A Y=5000 100 9000 : Digit Addition Pattern No. 000
8A Y=9000 0 8 : Addition of digit ā8ā
85 Y=5 22 07
Maximum number of digits dialed is 7.
25 07
DIGITAL CCIS PROGRAMMING
