CHAPTER 3 SYSTEM DATA PROGRAMMING
– 134 – NWA-008853-001 Rev.3.0
97ch3001.fm
DESCRIPTION DATA
[North America/µ-law countries]
[A-law countries]
E
CM42
T/R: Transmit/Receive
+: Gain
–: Loss
PATTERNS
2ND DATA
PAD DATA OF B TRUNK (T/R) [dB]
ODT (4W E&M) ODT (2W E&M) LDT
00
15
00 0/0 0/0 0/0
01 0/0 0/0 0/0
02 0/0 0/0 0/0
03 –2/–2 –3/–3 –3/–3
04 –3/–3 0/0 0/0
05 –12/–11 –6/–6 –6/–6
06 –16/–11 0/0 0/+5
07 –6/–6 0/0 +3/+3
08
15
Not Used
~
~
T/R: Transmit/Receive
+: Gain
–: Loss
PATTERNS
2ND DATA
PAD DATA OF B TRUNK (T/R) [dB]
ODT (4W E&M) ODT (2W E&M) LDT
00
15
00 0/0 0/0 0/0
01 0/0 0/0 0/0
02 0/0 0/0 0/0
03 –2/–2 –3/–3 –3/–3
04 –3/–3 0/0 0/0
05 –12/–11 –6/–6 –6/–6
06 –16/–11 0/0 0/+5
07 –6/–6 0/0 +3/+3
08
15
Not Used
~
~
END
ANALOG CCIS PROGRAMMING
