CHAPTER 3 SYSTEM DATA PROGRAMMING
– 168 – NWA-008853-001 Rev.3.0
97ch3002.fm
When a call is forwarded through CCIS by Call Forwarding-All Calls/-Busy Line/-Don’t Answer, the kind
of Call Forwarding and the station number which is setting the service can be indicated on the LCD of the
forwarding destination D
term
.
To provide this feature, do the following programming.
• On the forwarding side PBX (PBX-A)
• On the forwarded destination side PBX (PBX-B)
DESCRIPTION DATA
Provide the system with sending of Call For-
warding station information through CCIS.
(1)
(2)
373
0: To provide
DESCRIPTION DATA
Assign Service Restriction Class C to the re-
quired stations.
•
(1)
(2)
Y=07
X-XXXXXXXX: Station No.
XX: 00-15 : Service Restriction
Class C
Specify the LCD digits number of the D
term
as
24 digits.
•
(1)
(2)
Y=95
00-15: Service Restriction Class C as-
signed by CM12 Y=07
0: 24 digits
PBX-A
PBX-B
STATION
/TRUNK
CCIS
STATION 2000
Kind of Call Forwarding
Call Forwarding-All Calls/
Busy Line/Don’t Answer.
Call is forwarded from
Station 2000 by
and station number “2000”
are indicated on LCD.
START
CM08
END
START
CM12
CM15
END
JANUARY/31/2006
CALL FORWARDING-DON’T ANSWER-CCIS/MULTIPLE CALL FORWARDING-DON’T ANSWER-CCIS
