CHAPTER 3 SYSTEM DATA PROGRAMMING
– 196 – NWA-008853-001 Rev.3.0
97ch3003.fm
DESCRIPTION DATA
Specify Local Office or Center Office for Cen-
tralized Billing-CCIS
(1)
(2)
3
0 : Local Office
1 : Center Office
Assign maximum number of Call Record
sending to SMDR terminal 0.
NOTE: When the data is set to 1-23580, ex-
ternal alarm of memory overflew is
available, if CM44 2nd data=3000
is assigned.
(1)
(2)
0
0 : Not record
1-23580: 1 call-23580 calls
Assign maximum number of Call Record
sending to SMDR terminal 1.
NOTE: When the data is set to 1-23580, ex-
ternal alarm of memory overflew is
available, if CM44 2nd data=3002
is assigned.
(1)
(2)
1
0 : Not record
1-23580: 1 call-23580 calls
Assign maximum number of Call Record for a
local office of Centralized Billing-CCIS.
NOTE 1: When the data is set to 1-23580, ex-
ternal alarm of memory overflew is
available, if CM44 2nd data=3001
is assigned.
(1)
(2)
2
0 : Not record
1-23580: 1 call-23580 calls
NOTE 2: The amount of call record number set by CMDD02>0, 1, 2 must not exceed the following
number.
NOTE 3: CMDD02>0, 1, 2 are effective after executing CMDD98. Before executing CMDD98, be
sure to print out all of the stored call records. CMDD98 deletes all of the stored call
records.
A
CMDD00
CMDD02
Amount of Call Records number of CMDD02 1st data 0, 1, 2
No EXPMEM on AP00 (PN-AP00-B) is provided
EXPMEM on AP00 (PN-AP00-B)/
AP00 (PN-AP00-D) is provided
CMDD00>3 is set to 0
(Local Office of
Centralized Billing-
CCIS/Stand-alone)
CMDD00>3 is set to 1
(Center Office of
Centralized Billing-
CCIS)
CMDD00>3 is set to 0
(Local Office of
Centralized Billing-
CCIS/Stand-alone)
CMDD00>3 is set to 1
(Center Office of
Centralized Billing-
CCIS)
2620 1310 23580 22270
B
JULY/01/2006
CENTRALIZED BILLING-CCIS
