CHAPTER 3 SYSTEM DATA PROGRAMMING
– 204 – NWA-008853-001 Rev.3.0
97ch3003.fm
DESCRIPTION DATA
Set interface condition for AP00 card (PN-
AP00-B/PN-AP00-D with MRCA program)
RS port.
When you set CMDD01, the following initial
data is set to each port as the interface condi-
tion.
• Equipment Type: SMDR terminal 0 NOTE
• Data Speed: 1200 bps
• Stop Bit Length: 2 bits
• Data Length: 8 bits
• Parity: No Parity
• Station Address (SA): 0
• Unit Address (UA): !
• Message Format: Former NEAX 2400 IMS
Format
NOTE: When you set interface condition to
two ports, change one of those ports
of equipment type to SMDR terminal
1 by CMDD10>X00.
(1)
(2)
100 (Port 0)
101 (Port 1)
102 (Port 2)
103 (Port 3)
3: SMDR with NEAX 2400 IMS Format
To change the interface condition of each port
set by CMDD01, assign the attribute data, ac-
cording to the SMDR terminal specifications.
(1)
(2)
X00: Equipment Type Connected to
Port 0-3
X : 0-3: Port 0-3
1 : SMDR terminal 0
2 : SMDR terminal 1
(1)
(2)
X01: Data Speed for Port 0-3
X : 0-3: Port 0-3
1 : 300 bps
2 : 1200 bps
3 : 2400 bps
4 : 4800 bps
5 : 9600 bps
6 : 19200 bps
(1)
(2)
X02: Stop Bit Length for Port 0-3
X : 0-3: Port 0-3
0: 1 bit
1 : 1.5 bits
2: 2 bits
B
CMDD01
AP00 INITIAL
CMDD10
AP00 INITIAL
C
JULY/01/2006
CENTRALIZED BILLING-CCIS
To Next Page
