CHAPTER 3 SYSTEM DATA PROGRAMMING
– 211 – NWA-008853-001 Rev.3.0
97ch3003.fm
DESCRIPTION DATA
Assign the data as follows.
• For Local Office:
1st Data 2nd Data
CCIS channel No. 0
(0-7) for
Center Office
• For Tandem Office:
1st Data 2nd Data
CCIS channel No. 0
(0-7) for
Center Office
CCIS channel No. 1
(0-7) for
Local Office
See Example 3: Data Assignment of CMA7
Y=03, 04. Page 227
•
(1)
(2)
Y=03
0-7: CCIS channel No.
0 : Distant end is Center Office
1 : Distant end is Local Office
Assign Centralized Billing destination. •
(1)
(2)
Y=04
0-7: CCIS channel No.
00001-16367: Point Code of Center Office.
See Example 3: Data Assignment of CMA7
Y=03, 04. Page 227
Specify the station number sent to the 2400
IPX through CCIS for SMDR.
NOTE: If the Center Office is the 2400 IPX,
CM65 Y=26 is required.
•
(1)
(2)
Y=26
Tenant No. of Stations
0: My Line No.
1 : Sub Line No.
A
CMA7
CM65
B
CENTRALIZED BILLING-CCIS
